A Tractor Serves Several Purposes Portable Metal Marking Machine With Rotary
(Model:PEQD-025)
★Description
This is a multi-purpose portable metal marking machine, which can be disassembled for two purposes, and can be used as both a rotary pneumatic marking machine and a planar pneumatic marking machine. The marking method is relatively fashionable, and it can be marked by two-dimensional or three-dimensional word by word. portable metal marking machine
body is small and easy to carry, and the lifting column guide rail structure makes its structure stable and easy to operate. Using the working principle of linear track, the fuselage can adjust itself, and the working performance can be restored as before
★Application
1.Any transportable product
2.All kinds of parts and signs.
3.Smaller product accessories
4.Cylindrical and conical workpieces
★Product Features
1.The rotating head can be split so that it can achieve the effect of one machine with multiple functions.
2. The marking method is relatively novel, including two-dimensional marking and three-dimensional word-by-word marking.
3. The design of the machine body has the functions of self-lubricating, self-dustproof and sealing, which ensures the accuracy of the marking machine.
4. The lifting column guide rail structure makes its structure stable and easy to operate.
Strong compatibility, can print files in various formats
★Technical Parameters:
| Description | Dot Peen Marking Machine |
| Model | PEQD-100 | PEQD-025 | PEQD-030 |
| Machine Type | Flat Marking | Flat + Rotary Marking | Portable Type |
| Rotary Function | No | Yes | No |
| Chuck Diameter (Standard) | - | 125mm | - |
| Chuck Diameter (Optional) | - | 160mm/200mm/300mm | |
| Working Area | 150×100mm/300×200mm/ 400×300mm/200×100mm | 135×20mm/125×20mm 90×20mm/150×100mm 200×100mm |
| Marking Accuracy | 0.01 mm |
| Marking Depth | 0.01~2mm |
| Marking Speed | ≤50mm/s (for 3mm letter height/ 3-4 numbers/second) |
| Lifting Range | 0-300 mm |
| Machine Power | ≤400 W |
| Pin Hardness | HRC 92 |
| Power Supply | 220V±10％, 50HZ |
| Air Pressure | 0.2-0.6 Mpa |
| Working Environment | -5～40 ℃ |
| Whole Machine Weight | 60 Kgs | 70 kgs | 25 kgs |
★Sample Show
★Packaging & Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
★Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
