20W 30W 50W Popular Small 0.95MJ Air Cooled Jewelry Ceramic Electronic Laser Marker Machine
(Model:PEDB-400C)
★ Product Introduction:
Perfect Laser company launched laser marker machine PEDB-400C is a popular marking machine type on the market, compared with ordinary optical fiber laser marking machine, laser marker machine PEDB-400C marking effect is better, color is more distinct, marking out the product edge is also more neat, using Digital Galvanometer Laser Scanning Head, The marking efficiency can be improved while ensuring the accuracy of marking effect.
★ Product Features:
- Laser marking machine size is small, covers an area of 0.15 cubic meters, can be placed in any position for marking, save space.
- For a long use time, there will be no consumables in 8-10 years, maintenance-free.
- High work efficiency, using an imported scanning system, with a scanning speed of up to 7,000 mm / s.
- Integrated air cooling, with low loss rate.
- Laser marking machine adopts EZ-CAD control system, with high reliability and high stability.
- The laser marking machine depth marking with a depth of 1.0 mm on stainless steel and aluminum, and 0.2 mm-0.3 mm on YAG and diode markers.
- Integrated design, without the need to adjust the light path, the operation is easy to learn.
★ Application:
Laser marker machine has a wide range of applications, can be used in electronic products, hardware tools, jewelry, plastic keys, food and beverage, watch packaging and other products of the pattern of the text of the mark.
★ Technical Parameters:
| Model No | PEDB-400A | PEDB-400B | PEDB-400C laser marker machine | PEDB-400D |
| Type | Portable | Desktop | Colorful | Standby |
| Computer | Not includes PC | Includes PC |
| Laser Source |
| IPG Series | Pulsed, High Energy Ytterbium Fiber Lasers |
| Mode of operation | Pulsed |
| Polarization | random |
| Nominal average output power | 20W - 50W For PEDB-400A /400B /400C 20W - 100W For PEDB-400D |
| Central emission wavelength | 1060-1070 nm ,Q-switched operation Output power adjustment range 10%-100% |
| Emission Bandwidth (FWHM) | <10 nm |
| Long-term average power instability | <5% |
| Pulse width, (FWHM) | 100 ns |
| Laser switching ON time | 180 μsec |
| Laser switching OFF time | 180 μsec |
| Pulse Repetition Rate* kHz | 20-80 kHz |
| Energy per pulse (PRR = 20 kHz) | 0.95 mJ |
| Typical beam quality, M2 | <1.8 |
| Output fiber delivery length | 3m |
| Operating voltage | 220V |
| Max. Power consumption | 600W |
| Net Dimensions | 70*20*50cm | 80*38*72cm | 70*20*50cm | 143*62*101cm |
| Net Weight | 44 kgs | 53 kgs | 44 kgs | 130 kgs |
| Gross Weight | 60 kgs | 70 kgs | 60 kgs | 200 kgs |
| Laser system |
| Scanning Speed | 0-10000mm/s |
| Marking Speed | 0-7000mm/s |
| Marking size | 110mm×110mm (F-theta 160) |
| Spot size | ≤ 40 micron (F-theta 160) |
| Cooling unit | Air cooled |
| Pilot laser | 650nm diode laser, visible red light for marking guide |
| Continuous working time | ≥16h |
| Humidity | 45～85% (no condensation) |
| Operating temperature | 0~40℃ |
| Control units | Laser Mark (English Version) |
