Perfect Laser 1000W 1500W 2000W Cnc Laser Cutting Machine Sheet Metal Made in China
★ Product Introduction of Metal Laser Cutter :
Perfect laser cnc laser cutting machine sheet metal is a high-speed low-carbon steel cnc fiber laser cutting machine with 3000*1500mm working area, which is composed of machine tools, moving parts, electrical equipment control parts and other auxiliary parts. The three-axis moving parts of the cnc laser cutting machine sheet metal are operated by the control system to drive the movement of the fiber laser cutting head, which achieves stable, accurate and high-speed work.
★ Features of Metal Laser Cutter :
1. The fiber laser cutter has a gantry double drive structure and adopts imported rack and pinion transmission system to improve production efficiency.
2. High precision, fast speed, narrow cut, small heat-affected zone, smooth cutting surface and no burrs.
3. The laser cutting head does not touch the surface of the material and does not scratch the workpiece.
4. With good processing flexibility, any pattern can be processed.
5. The laser steel cutting machine can cut a variety of thin metal plates such as 3-5mm stainless steel and 4-6mm carbon steel.
★ Application of Metal Laser Cutter :
1.Applicable materials: 500w laser cutting metal machines is mainly used for non-contact cutting of thin metal plates, 3-5mm stainless steel, 4-6mm carbon steel, titanium alloy, galvanized steel, galvanized steel, silicon steel, pickling board, etc. fragile Alloy material plates. To
2. Industry applications: kitchen electrical, machine frame equipment, electrical equipment, sheet metal processing, precision metal parts (aerospace), electronic appliances, subway accessories, automotive machinery, metallurgical equipment, craft gifts, advertising signs, lighting hardware and other industries .
★ Technical Parameters of Metal Laser Cutter :
| Model | PE-F500-3015 |
| Laser Power | 500 watt |
| Laser Source | German IPG/ Sino-Tech / Raycus Fiber Laser Source |
| Laser Type | Fiber Laser |
| Laser Technology | Germany Technology |
| XYZ Working Area | 3000*1500*150mm |
| Max. Cutting Thickness (mm) | 1-5mm carbon steel |
| Max. Cutting Speed | 5-20 Meters / Min (up to Materials) |
| Max. Location Speed | 60m/min |
| Laser Wavelength | 1070nm |
| Minimum Line Width | ≤0.1mm |
| Location Precision | ≤±0.05mm |
| Re-Location Precision | ±0.02mm |
| Max. Moving Speed | 100m/min |
| Supporting Format | PLT, DXF, BMP, AI |
| Power Demand | 380V/50Hz |
| Cooling Way | Water Cooling |
| Worktable Max. Load | 1000 kgs |
| Transmission Method | Ball Screw Transmission |
| Table-Driven System | Japanese Imported Panasonic / Yaskawa Servo Motor & Driving System |
| Focus Method | Following and Automatic Adjust Focus |
| Control Method | Offline Movement Control |
| Control Software | Perfect Laser Professional Fiber Laser Cutting Software |
★ Machine parts of Metal Laser Cutter :
★ Packaging & Delivery:
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
★Competitive Advantages:
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
